CameraX 사진 깨지는 현상

안드로이드 CameraX에서 ImageProxy를 bitmap으로 바꾸는 과정에서 오류가 발생했다.



CameraX의 버전이 1.3.0 이상이라면 ImageProxy.toBitmap()을 사용하면 될것이지만 그 이하 버전은 해당 메소드를 지원되지 않는다.



하지만 CameraX는 1.3.0 compileSdkVersion이 34 이상이여야 한다고 한다.

Dependency 'androidx.camera:camera-extensions:1.3.0' requires 'compileSdkVersion' to be set to 34 or higher.
Compilation target for module ':app' is 'android-33'



물론 추후 compileSdkVersion나 targetSdk를 34로 업그레이드 시키겠지만 그건 좀 나중에 일이라서 우선 낮은 버전을 사용 할 때는 다른 대안을 생각해 봐야한다.



1. 첫번째 방식 (!!! 주의 : 틀린 방식 !!!)

처음 ImageProxy를 bitmap으로 바꾸는 코드들 찾았다.

(참고 링크 : https://stackoverflow.com/questions/56772967/converting-imageproxy-to-bitmap )



a. 먼저 ImageProxy를 Image 타입으로 바꾸고

@SuppressLint("UnsafeOptInUsageError") Image image = imageProxy.getImage();



b. 그 다음 아래와 같은 방식으로 바꾸는 것이다.

public Bitmap imageToBitmapFromAnalysis(Image image) {
    Image.Plane[] planes = image.getPlanes();
    ByteBuffer yBuffer = planes[0].getBuffer();
    ByteBuffer uBuffer = planes[1].getBuffer();
    ByteBuffer vBuffer = planes[2].getBuffer();

    int ySize = yBuffer.remaining();
    int uSize = uBuffer.remaining();
    int vSize = vBuffer.remaining();

    byte[] nv21 = new byte[ySize + uSize + vSize];
    //U and V are swapped
    yBuffer.get(nv21, 0, ySize);
    vBuffer.get(nv21, ySize, vSize);
    uBuffer.get(nv21, ySize + vSize, uSize);

    YuvImage yuvImage = new YuvImage(nv21, ImageFormat.NV21, image.getWidth(), image.getHeight(), null);
    ByteArrayOutputStream out = new ByteArrayOutputStream();
    yuvImage.compressToJpeg(new Rect(0, 0, yuvImage.getWidth(), yuvImage.getHeight()), 75, out);

    byte[] imageBytes = out.toByteArray();
    return BitmapFactory.decodeByteArray(imageBytes, 0, imageBytes.length);
}



하지만 모든 폰들이 정상적으로 이미지가 찍힌대로 바뀐것이 아니었다. 아래와 같이 이미지가 깨지는 폰들도 있었다.





2. 두번쨰 방식 : (해결 방법)

참고 링크 : https://stackoverflow.com/questions/65822326/why-camerax-image-distorted-when-saved-in-android-phone-redmi-9t



위에 링크에서 문제를 찾아보니 CameraX에서 나오는게 YUV_888_420 버퍼고 이것을 NV21인 것으로 가정해서 나온 코드인 것 같다.



하지만 모든 YUV_888_420 버퍼가 NV21 형식이라고 가정해서는 안 되고, YUV_888_420 는 NV12, YU12 또는 YV12 형식일 수도 있다는 것이다.



그래서 제안하는 것이 YUV images 를 RGB bitmaps 으로 바꾸라는 것이다. (YuvToRgbConverter.kt)



그래서 YuvToRgbConverter.kt 파일을 그대로 추가해주고 사용하려는 곳에 가져와 초기화 시켜주고



1. 먼저 추가한 파일을 사용하기 위해 YuvToRgbConverter 초기화

YuvToRgbConverter yuvToRgbConverter = new YuvToRgbConverter(mContext);



2. ImageAnalysis에 바로 사용해도 되지만 너무 길어지는 것 같아 processImage 메소드로 따로 만들어서 사용

private ImageAnalysis.Analyzer setImageAnalyzer() {
    ImageAnalysis.Analyzer analyzer = new ImageAnalysis.Analyzer() {
        @Override
        public void analyze(@NonNull ImageProxy image) {
            processImage(image);
            image.close();

            try {
                Thread.sleep(1000);
            } catch (InterruptedException e) {
                e.printStackTrace();
            }
        }
    };
    return analyzer;
}



3. processImage 메소드

   public void processImage(@NonNull ImageProxy imageProxy) {

        @SuppressLint("UnsafeOptInUsageError") Image image = imageProxy.getImage();

        Bitmap passportBitmap = Bitmap.createBitmap(imageProxy.getWidth(), imageProxy.getHeight(), Bitmap.Config.ARGB_8888); // 비트맵 객체 생성
        yuvToRgbConverter.yuvToRgb(image, passportBitmap);

        // passportBitmap으로 원하는 작업 수행
  }



• ImageProxy를 Image 타입으로 바꿔준다.
• Bitmap을 ImageProxy 크기에 맞게 만들어주고
• YuvToRgbConverter의 yuvToRgb 메소드에 (1) Image와 (2) Bitmap을 파라미터로 넣어주면 끝난다.



YuvToRgbConverter.kt  코드:

/*
 * Copyright 2020 The Android Open Source Project
 *
 * Licensed under the Apache License, Version 2.0 (the "License");
 * you may not use this file except in compliance with the License.
 * You may obtain a copy of the License at
 *
 *     https://www.apache.org/licenses/LICENSE-2.0
 *
 * Unless required by applicable law or agreed to in writing, software
 * distributed under the License is distributed on an "AS IS" BASIS,
 * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
 * See the License for the specific language governing permissions and
 * limitations under the License.
 */

package com.example.android.camera.utils

import android.content.Context
import android.graphics.Bitmap
import android.graphics.ImageFormat
import android.graphics.Rect
import android.media.Image
import android.renderscript.Allocation
import android.renderscript.Element
import android.renderscript.RenderScript
import android.renderscript.ScriptIntrinsicYuvToRGB
import android.renderscript.Type
import java.nio.ByteBuffer

/**
 * Helper class used to efficiently convert a [Media.Image] object from
 * [ImageFormat.YUV_420_888] format to an RGB [Bitmap] object.
 *
 * The [yuvToRgb] method is able to achieve the same FPS as the CameraX image
 * analysis use case on a Pixel 3 XL device at the default analyzer resolution,
 * which is 30 FPS with 640x480.
 *
 * NOTE: This has been tested in a limited number of devices and is not
 * considered production-ready code. It was created for illustration purposes,
 * since this is not an efficient camera pipeline due to the multiple copies
 * required to convert each frame.
 */
class YuvToRgbConverter(context: Context) {
    private val rs = RenderScript.create(context)
    private val scriptYuvToRgb = ScriptIntrinsicYuvToRGB.create(rs, Element.U8_4(rs))

    private var pixelCount: Int = -1
    private lateinit var yuvBuffer: ByteBuffer
    private lateinit var inputAllocation: Allocation
    private lateinit var outputAllocation: Allocation

    @Synchronized
    fun yuvToRgb(image: Image, output: Bitmap) {

        // Ensure that the intermediate output byte buffer is allocated
        if (!::yuvBuffer.isInitialized) {
            pixelCount = image.cropRect.width() * image.cropRect.height()
            // Bits per pixel is an average for the whole image, so it's useful to compute the size
            // of the full buffer but should not be used to determine pixel offsets
            val pixelSizeBits = ImageFormat.getBitsPerPixel(ImageFormat.YUV_420_888)
            yuvBuffer = ByteBuffer.allocateDirect(pixelCount * pixelSizeBits / 8)
        }

        // Rewind the buffer; no need to clear it since it will be filled
        yuvBuffer.rewind()

        // Get the YUV data in byte array form using NV21 format
        imageToByteBuffer(image, yuvBuffer.array())

        // Ensure that the RenderScript inputs and outputs are allocated
        if (!::inputAllocation.isInitialized) {
            // Explicitly create an element with type NV21, since that's the pixel format we use
            val elemType = Type.Builder(rs, Element.YUV(rs)).setYuvFormat(ImageFormat.NV21).create()
            inputAllocation = Allocation.createSized(rs, elemType.element, yuvBuffer.array().size)
        }
        if (!::outputAllocation.isInitialized) {
            outputAllocation = Allocation.createFromBitmap(rs, output)
        }

        // Convert NV21 format YUV to RGB
        inputAllocation.copyFrom(yuvBuffer.array())
        scriptYuvToRgb.setInput(inputAllocation)
        scriptYuvToRgb.forEach(outputAllocation)
        outputAllocation.copyTo(output)
    }

    private fun imageToByteBuffer(image: Image, outputBuffer: ByteArray) {
        assert(image.format == ImageFormat.YUV_420_888)

        val imageCrop = image.cropRect
        val imagePlanes = image.planes

        imagePlanes.forEachIndexed { planeIndex, plane ->
            // How many values are read in input for each output value written
            // Only the Y plane has a value for every pixel, U and V have half the resolution i.e.
            //
            // Y Plane            U Plane    V Plane
            // ===============    =======    =======
            // Y Y Y Y Y Y Y Y    U U U U    V V V V
            // Y Y Y Y Y Y Y Y    U U U U    V V V V
            // Y Y Y Y Y Y Y Y    U U U U    V V V V
            // Y Y Y Y Y Y Y Y    U U U U    V V V V
            // Y Y Y Y Y Y Y Y
            // Y Y Y Y Y Y Y Y
            // Y Y Y Y Y Y Y Y
            val outputStride: Int

            // The index in the output buffer the next value will be written at
            // For Y it's zero, for U and V we start at the end of Y and interleave them i.e.
            //
            // First chunk        Second chunk
            // ===============    ===============
            // Y Y Y Y Y Y Y Y    V U V U V U V U
            // Y Y Y Y Y Y Y Y    V U V U V U V U
            // Y Y Y Y Y Y Y Y    V U V U V U V U
            // Y Y Y Y Y Y Y Y    V U V U V U V U
            // Y Y Y Y Y Y Y Y
            // Y Y Y Y Y Y Y Y
            // Y Y Y Y Y Y Y Y
            var outputOffset: Int

            when (planeIndex) {
                0 -> {
                    outputStride = 1
                    outputOffset = 0
                }
                1 -> {
                    outputStride = 2
                    // For NV21 format, U is in odd-numbered indices
                    outputOffset = pixelCount + 1
                }
                2 -> {
                    outputStride = 2
                    // For NV21 format, V is in even-numbered indices
                    outputOffset = pixelCount
                }
                else -> {
                    // Image contains more than 3 planes, something strange is going on
                    return@forEachIndexed
                }
            }

            val planeBuffer = plane.buffer
            val rowStride = plane.rowStride
            val pixelStride = plane.pixelStride

            // We have to divide the width and height by two if it's not the Y plane
            val planeCrop = if (planeIndex == 0) {
                imageCrop
            } else {
                Rect(
                    imageCrop.left / 2,
                    imageCrop.top / 2,
                    imageCrop.right / 2,
                    imageCrop.bottom / 2
                )
            }

            val planeWidth = planeCrop.width()
            val planeHeight = planeCrop.height()

            // Intermediate buffer used to store the bytes of each row
            val rowBuffer = ByteArray(plane.rowStride)

            // Size of each row in bytes
            val rowLength = if (pixelStride == 1 && outputStride == 1) {
                planeWidth
            } else {
                // Take into account that the stride may include data from pixels other than this
                // particular plane and row, and that could be between pixels and not after every
                // pixel:
                //
                // |---- Pixel stride ----|                    Row ends here --> |
                // | Pixel 1 | Other Data | Pixel 2 | Other Data | ... | Pixel N |
                //
                // We need to get (N-1) * (pixel stride bytes) per row + 1 byte for the last pixel
                (planeWidth - 1) * pixelStride + 1
            }

            for (row in 0 until planeHeight) {
                // Move buffer position to the beginning of this row
                planeBuffer.position(
                    (row + planeCrop.top) * rowStride + planeCrop.left * pixelStride)

                if (pixelStride == 1 && outputStride == 1) {
                    // When there is a single stride value for pixel and output, we can just copy
                    // the entire row in a single step
                    planeBuffer.get(outputBuffer, outputOffset, rowLength)
                    outputOffset += rowLength
                } else {
                    // When either pixel or output have a stride > 1 we must copy pixel by pixel
                    planeBuffer.get(rowBuffer, 0, rowLength)
                    for (col in 0 until planeWidth) {
                        outputBuffer[outputOffset] = rowBuffer[col * pixelStride]
                        outputOffset += outputStride
                    }
                }
            }
        }
    }
}
